Commercial Gates | Double Gates | CG5
£394.75+ Price depends upon Sizes
This design shows a pair of green-framed commercial mesh double gates, each leaf split into four braced panels with diagonal cross supports and a fine steel mesh infill. The heavy-duty box-section perimeter frame and triple hinge points shown in the drawing make this a robust option for securing wide commercial openings.
Description
This technical drawing illustrates a pair of commercial mesh double gates finished in a deep green powder coat, designed to secure wide industrial or commercial entrances. The layout shows each leaf divided into four braced panels with a fine steel mesh infill, giving a design that balances visibility through the gate with a solid, structured appearance suited to sites where security and clear sightlines both matter.
Design Features Shown in the Drawing
The drawing of these commercial mesh double gates sets out a clear panel structure and hardware layout across both leaves.
Panel Layout and Bracing
- Each leaf is split into four equal panels using a horizontal mid-rail and vertical centre stile
- Every panel includes a diagonal cross-brace design running corner to corner for added rigidity
- Fine square mesh infill is fitted within each braced panel section
Frame and Hardware Detail
- A heavy box-section perimeter frame runs around each leaf, shown as the thicker green outline
- Three hinge points are marked along the outer edge of each leaf for even weight distribution
- A central locking box sits at the meeting stiles where the two leaves close together
Specifications of This Commercial Mesh Double Gate Design
The drawing indicates a double-leaf configuration built for wide commercial or industrial vehicle and pedestrian access points.
- Two matching leaves of equal width, hinged on opposite outer posts
- Green powder-coated finish shown throughout the frame and mesh
- Fine mesh panel infill for through-visibility and reduced foothold
- Diagonal bracing within each of the eight panel sections across both leaves
- Three-point hinge fixing per leaf as marked in the drawing
Why Specify This Gate for a Commercial Site
These commercial mesh double gates suit sites needing a wide, secure opening without sacrificing sightlines across the boundary line. The braced panel structure shown in the drawing is designed to keep each leaf square and resist sagging over a wide span, while the mesh infill allows staff and site managers to see through to the entrance from either side.
The double-leaf format also makes this design practical for openings that need to accommodate larger vehicles, with each leaf swinging independently for standard access or opening fully for wider loads.
Ordering and Delivery
As this commercial mesh double gate design is British made to order, sizes can be adjusted to match the exact opening width and height required on site. Nationwide UK delivery is available once the specification is confirmed.
Frequently Asked Questions
Can the mesh panel size be adjusted on these commercial mesh double gates?
The mesh density shown in the drawing can typically be discussed at order stage to suit the level of visibility or security required for the site.
Is this double gate design suitable for vehicle entrances?
Yes, the double-leaf layout with a box-section perimeter frame shown in the drawing is intended for wider commercial and vehicle access points rather than narrow pedestrian gaps.
What finish is shown on this gate drawing?
The drawing shows a green powder-coated finish applied across the full frame, mid-rails, cross-braces and mesh infill of both leaves.
Specifications
We are the only manufacturing brand who not only provide bespoke design and sizes but also the specifications for gates.
Our material, size of rails, frames, infill bars and article designs are depending upon the requirements of each gate so you can get the best results. The standard size for side frame section starts at 40mm x 40mm but some basic side or garden gates can be made using 20mm x 10mm,20mm x20mm etc. frames as well. The specifications for all the premium gates will be decided by us according to the design and size of gates, we will give you the best option so that the quality of gate will not be compromised.
| Specifications
GATES |
Frame Section | Top/Arch Section | Infill Bars | Privacy Sheet | Operating System | Gate Arts |
| Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Side Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Garden Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Sliding Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Security Door | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Alleyway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| ¾ Split Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| BiFold Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Railing | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | N/A | Depend upon railing selection |
How To Measure
- Take 3 measurements: Top, Middle and Bottom
- Use the smallest of widths as Total Gap Width
- This is all we need, leave the rest of fittings upon us.
Post & Hinges Guide
Any question please call Us on 02089116000 – we are happy to help.
