Commercial Gates | Double Gates | CG8

Description

This drawing sets out the CG8 double leaf mesh security gate, a two-leaf commercial swing gate finished in green with a dense vertical bar infill running across both panels. The design combines a robust outer frame with tightly spaced mesh bars, giving it the look of a high-security barrier suited to commercial, industrial or perimeter applications where restricted visibility gaps and a solid presence matter.

Design and Layout Shown in the Drawing

The sketch shows a symmetrical double leaf mesh security gate made up of two identical leaves of equal width, each framed by a heavy green border section running around the top, bottom and sides. Within each frame, closely spaced vertical mesh bars fill the entire panel from top rail to bottom rail, leaving very little gap between bars.

Frame and Infill

• Heavy-section green perimeter frame around each leaf
• Dense vertical bar mesh infill spanning the full height of both panels
• Consistent bar spacing across the entire width for a uniform screening effect

Hinge and Lock Detail

• Hinge fixing points marked on the outer vertical edge of each leaf
• A central square locking box positioned where the two leaves meet at mid-height
• Meeting stiles aligned centrally to allow the gate to close flush

Specifications Visible in the Design

As drawn, this double leaf mesh security gate is configured as two equal leaves rather than a single-swing panel, making it suited to wider openings such as commercial entrances or vehicle access points. The frame is shown in a green finish with the mesh infill matching the same colour throughout, giving a consistent appearance across the whole structure.

• Two-leaf swing gate configuration with matching panel widths
• Green painted finish applied to frame and mesh infill
• Hinge points positioned on the outer edges of each leaf for wall or post fixing
• Central lock box detail for a secure meeting-point closure

Why Consider This Gate Style

The narrow bar spacing shown in this double leaf mesh security gate drawing supports a strong visual security deterrent while still allowing a degree of visibility through the panel. The double-leaf layout also makes it a practical choice where a wide opening needs to be split into two manageable, independently operable sections rather than one large single gate.

• Suited to commercial, industrial or site perimeter openings
• Split-leaf format eases day-to-day opening and closing
• Uniform mesh pattern designed for a tidy, consistent line across the full width

Frequently Asked Questions

Is this gate design suitable for wide openings?

Yes, the double leaf mesh security gate layout shown in this drawing splits a wide opening into two matching panels, which is typically easier to install and operate than one very large single leaf.

What finish is shown on the gate in the drawing?

The drawing shows a green painted finish applied consistently across both the outer frame and the vertical mesh infill of each leaf.

Where is the locking point positioned on this design?

The central locking box is shown at the meeting point of the two leaves, roughly mid-height, allowing both panels to be secured together when closed.
