Metal Railings | Iron Fencing | Window Security Grill Bars | Metal Grilles |UKMR40
£199.96+ Price depends upon Sizes
This design shows a metal railing panel with alternating twisted balusters and straight bars, each finished with fleur-de-lis style scrollwork and a bolder double-scroll centrepiece. The layout gives a traditional wrought iron look with strong security spacing between verticals.
Description
This drawing sets out a decorative scroll metal railings panel built from evenly spaced vertical bars, combining twisted balusters with straight uprights and finished with hand-forged style scrollwork. The design gives a classic ironwork appearance while keeping a practical bar spacing suitable for boundary and balcony use, making it a strong choice for anyone wanting decorative scroll metal railings with genuine visual detail rather than a plain flat-bar panel.
Design Details Shown in the Drawing
The layout of this decorative scroll metal railings panel alternates twisted “barley-twist” balusters with plain straight bars across the full width, creating rhythm along the run.
Repeating Scroll Motifs
Each straight bar section carries a small double-scroll, fleur-de-lis style flourish positioned at lower-mid height, repeated consistently across the panel for a balanced, symmetrical finish.
Central Feature Panel
At the centre of the drawing sits a larger, more elaborate scroll motif — a tall double-scroll “butterfly” style design flanked by two straight uprights with a twisted centre bar. This central section is visibly taller in detail than the surrounding bays, marking it out as a feature point within the run.
Specifications of This Railing Design
The technical drawing indicates a top and bottom horizontal rail with evenly spaced vertical infill bars running between them, typical of a fabricated metal railing panel.
- Alternating twisted and straight vertical bars
- Fleur-de-lis style double-scroll detail on repeated bays
- Larger ornamental double-scroll centrepiece bay
- Top and bottom horizontal rail framing the panel
- Consistent bar spacing suitable for railing or fencing runs
Why Choose This Scroll Railing Design
Choosing this decorative scroll metal railings pattern gives a traditional, ornamental appearance without departing from a straightforward, repeatable panel structure that suits long boundary runs or feature sections.
- Symmetrical scroll detailing for a balanced finished look
- Twisted bar sections add texture alongside the straight uprights
- Central motif can act as a focal point within a longer railing run
- Panel structure supports UK-wide fabrication and delivery
Frequently Asked Questions
Can this railing design be made to a custom width?
Yes, the panel layout shown can be adapted to different widths by adjusting the number of repeated scroll bays while keeping the central feature section intact.
Is this decorative scroll metal railings design suitable for both fencing and balconies?
The bar spacing and horizontal top/bottom rail shown in the drawing suit general fencing, boundary, and railing applications where a decorative finish is wanted.
Does the centrepiece scroll always sit in the middle?
As drawn, the larger double-scroll motif is positioned centrally, with the repeating smaller scroll bays arranged symmetrically on either side.
Specifications
We are the only manufacturing brand who not only provide bespoke design and sizes but also the specifications for gates.
Our material, size of rails, frames, infill bars and article designs are depending upon the requirements of each gate so you can get the best results. The standard size for side frame section starts at 40mm x 40mm but some basic side or garden gates can be made using 20mm x 10mm,20mm x20mm etc. frames as well. The specifications for all the premium gates will be decided by us according to the design and size of gates, we will give you the best option so that the quality of gate will not be compromised.
|
Specifications GATES |
Frame Section |
Top/Arch Section | Infill Bars | Privacy Sheet | Operating System | Gate Arts |
|
Driveway Gate |
40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Side Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Garden Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Sliding Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Security Door | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Alleyway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| ¾ Split Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| BiFold Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Railing | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | N/A | Depend upon railing selection |
How To Measure
- Take 3 measurements: Top, Middle and Bottom
- Use the smallest of widths as Total Gap Width
- This is all we need, leave the rest of fittings upon us.
Post & Hinges Guide
Any question please call Us on 02089116000 – we are happy to help.
