Composite Side Gate | Side Gates | CSG9
Original price was: £490.84.£300.00Current price is: £300.00.+ Price depends upon Sizes
This ornate composite side gate design combines fine vertical slats with a scrolled diamond lattice and gold-tone diamond infill panels for a striking decorative finish. The graphite outer frame with visible hinge plates and a side handle gives the design a secure, ready-to-fit appearance.
Description
This ornate composite side gate design, shown as the CSG9 render, brings together intricate scrollwork, a diamond lattice centrepiece and warm gold-tone panelling within a solid graphite frame. The layout is built for narrow side passages and garden entrances where a decorative yet structured look is wanted, combining traditional wrought-iron style detailing with a modern composite construction.
Design Details of This Ornate Composite Side Gate
The design centres around a striking pattern of interlocking diamonds running down the middle of the gate. Each gold-toned diamond panel alternates with an open diamond space filled with a delicate fleur-de-lis style scroll medallion, set against a backdrop of narrow vertical bars.
Scrollwork Side Panels
Flanking the central diamond column, the render shows two vertical bands filled with symmetrical C-scroll and spiral ironwork motifs, mirrored on both the left and right sides for a balanced, classical appearance.
Frame and Fittings
The gate is set within a bold rectangular graphite-coloured frame, with hinge plates visible along the left edge and a handle with a keyhole positioned on the right, indicating a single-opening side gate configuration.
Features of the CSG9 Ornate Composite Side Gate
This ornate composite side gate design brings together decorative and functional elements suited to a side entrance setting.
- Diamond lattice pattern with contrasting gold-tone infill panels
- Scrolled fleur-de-lis medallions set within open diamond sections
- Symmetrical scrollwork side panels with spiral and C-scroll detailing
- Solid graphite outer frame with visible hinge plate fixings
- Side-mounted handle and keyhole fitting for single-gate operation
Why Choose This Ornate Composite Side Gate Design
The combination of a structured frame with ornamental ironwork-style detailing makes this design suited to properties looking for a decorative side gate that still reads as solid and secure. The layered pattern of diamonds, scrolls and vertical slats gives visual depth without overcomplicating the overall silhouette, making it a versatile match for period and contemporary property fronts alike.
Specifications Shown in the Render
The specification visible in this ornate composite side gate render reflects a single-leaf gate designed for a side passage opening.
- Single-gate leaf with two hinge fixing points
- Rectangular composite frame in a graphite finish
- Mixed panel design: vertical slats, scrollwork and diamond lattice sections
- Gold-tone accent panels within the central diamond pattern
- Handle and lock fitting positioned on the leading edge
Frequently Asked Questions
Is this design suitable for a narrow side passage?
Yes, the single-leaf layout with hinge fixings on one side and a handle on the other is designed for use as a side gate rather than a double-leaf driveway entrance.
Can the diamond panel colours be matched to other schemes?
The render shows gold-tone diamond infill panels against a graphite frame, and colour options may vary, so it is worth confirming finish choices before ordering.
Does this gate include a locking mechanism?
The design shown includes a handle with a keyhole fitting on the right-hand edge, indicating a lockable side gate suited to secure side access.
Specifications
We are the only manufacturing brand who not only provide bespoke design and sizes but also the specifications for gates.
Our material, size of rails, frames, infill bars and article designs are depending upon the requirements of each gate so you can get the best results. The standard size for side frame section starts at 40mm x 40mm but some basic side or garden gates can be made using 20mm x 10mm,20mm x20mm etc. frames as well. The specifications for all the premium gates will be decided by us according to the design and size of gates, we will give you the best option so that the quality of gate will not be compromised.
| Specifications
GATES |
Frame Section | Top/Arch Section | Infill Bars | Privacy Sheet | Operating System | Gate Arts |
| Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Side Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Garden Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Sliding Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Security Door | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Alleyway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| ¾ Split Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| BiFold Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Railing | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | N/A | Depend upon railing selection |
How To Measure
- Take 3 measurements: Top, Middle and Bottom
- Use the smallest of widths as Total Gap Width
- This is all we need, leave the rest of fittings upon us.
Post & Hinges Guide
Any question please call Us on 02089116000 – we are happy to help.
