Composite Side Gate | Side Gates | CSG13
Original price was: £411.84.£300.00Current price is: £300.00.+ Price depends upon Sizes
This composite side gate design combines a wood-effect composite panel with an arched vertical bar railing section and a diamond trellis base, all framed in black metal. The layered, curved sections give it a distinctive tri-tone look while the composite infill offers a low-upkeep alternative to solid timber boarding.
Description
This composite side gate design brings together three distinct sections within a single black metal frame: an arched top of vertical bar railings, a central wood-effect composite panel, and a lower diamond trellis infill. The render shows each section divided by a sweeping curved line rather than a straight edge, giving the gate a flowing, wave-like profile that sets it apart from a standard flat-panel side gate.
Design Features of This Composite Side Gate
The standout feature of this composite side gate design is the way three contrasting materials are combined within one frame, rather than relying on a single uniform infill.
Arched Railing Top
The upper portion follows a gentle arch and is fitted with closely spaced vertical bars, allowing light and visibility through the top of the gate while maintaining the boundary line.
Wood-Effect Composite Panel
Below the railings sits a run of vertical composite slats in a brown wood-effect finish, giving the appearance of timber boarding for privacy across the main body of the gate.
Diamond Trellis Base
The lowest section is finished with a black diamond lattice mesh, echoing the open-bar theme of the top railing and completing the layered look shown in the render.
Specifications Shown in the Render
The specification of this composite side gate design is built around a black powder-coated metal frame that houses the three infill types.
- Black metal outer frame with an arched top rail
- Vertical bar railing section at the top of the gate
- Vertical wood-effect composite slats through the mid-section
- Diamond trellis mesh panel at the base
- Two visible hinge points on the left-hand post
- Side-mounted handle and lock plate on the right-hand edge
Why Choose This Side Gate Style
Choosing this composite side gate design suits homeowners who want a boundary gate that looks distinct from typical solid timber or plain metal options. The combination of open bar sections and a solid composite panel offers a balance between privacy across the middle of the gate and light penetration at the top and bottom, while the black frame provides a strong, defined outline around each material.
Frequently Asked Questions
What materials are shown in this composite side gate design?
The render shows a black metal frame combined with a brown wood-effect composite slat panel, vertical metal bar railings, and a metal diamond trellis mesh section.
Does this gate offer full privacy?
Privacy is provided across the central composite slat section, while the top railing and bottom trellis panel are open, allowing partial visibility and airflow through those areas.
Where is the gate handle positioned?
The handle and lock plate are shown fitted on the right-hand side of the gate, with hinge fixings positioned on the opposite left-hand post.
Specifications
We are the only manufacturing brand who not only provide bespoke design and sizes but also the specifications for gates.
Our material, size of rails, frames, infill bars and article designs are depending upon the requirements of each gate so you can get the best results. The standard size for side frame section starts at 40mm x 40mm but some basic side or garden gates can be made using 20mm x 10mm,20mm x20mm etc. frames as well. The specifications for all the premium gates will be decided by us according to the design and size of gates, we will give you the best option so that the quality of gate will not be compromised.
| Specifications
GATES |
Frame Section | Top/Arch Section | Infill Bars | Privacy Sheet | Operating System | Gate Arts |
| Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Side Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Garden Gate | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Sliding Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Security Door | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Alleyway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| ¾ Split Driveway Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| BiFold Gate | 40mm X 40mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box ) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | Manual or Electric | Depend upon gate selection |
| Railing | 20mm X 20mm -100mm X 100 mm | 40mm X 8mm (Min Flat bar) or 40mm X 40mm(Box) | 12mm-20mm round bar, square bar(solid & hallow) | 1mm – 3mm thick | N/A | Depend upon railing selection |
How To Measure
- Take 3 measurements: Top, Middle and Bottom
- Use the smallest of widths as Total Gap Width
- This is all we need, leave the rest of fittings upon us.
Post & Hinges Guide
